| YX600UTV | 整车参数 |
| ENGINE |
| Type | 594cc,单缸、4冲程、单顶置凸轮轴4气门,油冷加水冷 |
| Bore x Stroke | 96mm x 82mm |
| Compression Ratio | 9.8:1 |
| Rated power | 27kw/5500rpm |
| Rated.torque | 55Nm/4250rpm |
| Ignition | EFI |
| Starting | 电 |
| Transmission | L-H-N-R |
| Drive Train | 轴传动 |
| CHASSIS |
| Suspension/Front | Independent double swing arm |
| Suspension/Rear | Independent double swing arm |
| Brakes/Front | Dual ventilated hydraulic disc |
| Brakes/Rear | Dual ventilated hydraulic disc |
| Tires/Front | AT25 x 8-12 radial |
| Tires/Rear | AT25 x 10-12 radial |
| DIMENSIONS |
| L x W x H | 3025mm x1570mm x 1900mm |
| Quotation | Seat Height | 830mm |
| Wheelbase | 1920mm |
| Ground Clearance | 290mm |
| Fuel Capatity | 29L |
| 最大总质量 | 645Kg |
| Dry Weight | 620Kg |
| 转弯半径 | 4250mm |
| Loading Quantity | 14 units/1×40HQ，3units/1×20GP |
| Optional | OTHER |
| Lighting | 12V 35W/35W × 2,12V 5W × 2,12V 10W×2(front); 12V 5W/21W × 2,12V 10W×2,12V 10W×2(rear);12V 5W×1 |
